Sub-Zero Wolf MDD30TE/S/TH

Page 42
#826151 - Revision A - March, 2016
6-5
Wiring
Microwave Drop-Down Door Series
Microwave Drop-Down Door Series
WIRING SCHEMATICS
MODEL: MDD30CM-B-TH
MAIN SUPPLY CORD
TURNTABLE MOTOR
GREEEN/YELLOW
WHITE
BLACK
WHITE
BLACK
WHITE
BLACK
WHITE WHITE
RED
NOISE FILTER
GREEN
BLACK
GREEN
ORANGE
BLACK
RED
RED
BLACK
OVEN THERMAL
CUT-OUT
H.V.
TRANSFORMER
WHITE
ORANGE
WHITE
RED
FAN MOTOR
H.V. RECTIFIER
H.V. CAPACITOR
RED
ORANGE
BLUE
WHITE RED
MAGNETRON
CN-F
CN-B
RY1
RY2
ORANGE
ORANGE
RED
WHITE WHITE
GRAY
GREEN BLACK
CN-301 CN-A
CN-C
MAGNETRON
THERMAL
CUT-OUT
LED LIGHT
ORANGE
ORANGE
BLACK
WHITE
RED
WHITE
WHITE
GRAY
BLUE
BLK
RED
RED
WHITE BLACK
ORANGE BLUE BLUE
- This wiring information is provided for use by qualified service personnel only.
- Disconnect appliance from electrical supply before begining service.
- Be sure all grounding devices are connected when service is complete.
- Failure to observe the above warnings may result in severe electrical shock.
