4-11
Climate control
– CONTINUED –
85° F(18–32° C).
NOTE
The temperature is shown in units of Fahrenheit
for the US model and in Centigrade for the Canadi-
an model.
T Control panel
1) Temperature control dial
2) AUTO switch
3) Fan speed control dial
4) Air conditioner switch
5) Air flow control dial
6) Defroster switch
7) Rear window defogger switch (Refer to the “Rear win-
dow defogger switch” in chapter 3.)
8) Air inlet selection switch
9) OFF/BRIGHT switch
T AUTO switch
AUTO mode operation:
When the “AUTO” switch is pressed, the indicator light
on the switch illuminates, indicating that the Automatic
Climate Control system is operating in the automatic
mode. In the automatic mode, the system maintains
the desired cabin air temperature (this is set using the
temperature control dial) by automatically controlling
the fan speed, air flow mode, air inlet selection, and air
conditioner compressor operation.
123456
789
HS4019BB
HS4023BA
