8-19
Driving tips
– CONTINUED –
3. Carefully raise the crossbar from roof rails.
NOTE
It may be necessary to move the Front crossbar
rearward, near the center of the roof rail for easier
removal. Use care not to cross-thread the screw in
the insert if it has been removed.
V To install the crossbar
Front crossbar:
Front crossbar has 150 LBS. Load Label on right-hand
side.
1) Crossbar end support
2) T-30 torx® head screw
1. Before placing the crossbar on the roof rails, make
sure that the T-30 torx® head screw is fully loosened
from each end support.
2. Spread the inner clamp and the end support as far
apart as possible.
HS8025BA
1
2
HS8028BB
To Next Page
