Subaru 2007 Impreza - Page 37

2007 New Model Update (916)
2007 Subaru B9 Tribeca Page 37
* Refer to STIS (Subaru Technical Infromation System) *** New Feature
June 2006
16. Orange Security Recovery Battery voltage. 10Hz square wave to ground for
less than 10 second when security system
activated during RES operation.
17. Dark Brown Program Button Ground
18. Dark Brown Program Button Battery voltage. When pushing program
button value goes to ground.
19. Gray Hood Switch Hood closed battery voltage.
Hood open 0 volts
20. White Battery Battery voltage.
21. Red/White Horn Output Battery voltage.
Tracer Horn Relay 0 volts when horn sounds
