222
2-2. Instrument cluster
BRZ_EGE
*
1
: These lights turn on when the push-button ignition switch is turned
to “ON” mode to indicate that a system check is being performed.
They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on,
or if the lights do not turn off. We recommend that you have your
vehicle inspected by any authorized SUBARU dealer or repairer, or
another duly qualified and equipped professional for details.
*
2
: This indicator turns on when the engine coolant temperature is low.
*
3
: The light flashes to indicate that the system is operating.
*
4
: When the outside temperature is approximately 3°C (37°F) or lower,
the indicator will illuminate.
*
5
: When the system is functioning normally and the push-button igni-
tion switch is turned to “ON” mode, both the “ON” and “OFF” indica-
tors of the front passenger’s front airbag manual ON-OFF indicator
illuminate for 6 seconds. After that, both the “ON” and “OFF” indica-
tor lights turn off for 2 seconds. Then, either the “ON” or “OFF” indi-
cator light illuminates depending on the status of the front
passenger’s front airbag manual cut off switch. If the system is mal-
functioning, the “OFF” indicator light illuminates regardless of the
condition of the front passenger’s front airbag manual cut off switch
when the push-button ignition switch is turned to “ON” mode.
If a system malfunction has occurred, move the front passenger to
the rear seat. Then, we recommend that you have your vehicle
inspected by any authorized SUBARU dealer or repairer, or another
duly qualified and equipped professional immediately.
(Green)
Cruise control indicator
(→P. 252)
Low outside tempera-
ture indicator (→P. 236)
“SET” indicator
(→P. 252)
Front passenger’s front airbag manual ON-OFF
indicator (→P. 172)
*
4
*
5
