SUBARU CROSSTREK SEDAN
SPN0002704 FRONT ALIGNMENT TEMPLATES
FRONT SIDE PLATE INSTALL TEMPLATES
2.3" (59.2 mm) 2.1" (52.30 mm)
6.6" (167.4 mm)
5.4" (135.9 mm)
LOCATE SIDE OF SILL PLATE HERE
LOCATE SIDE OF SILL PLATE HERE
LOCATE SIDE OF SILL PLATE HERE
LOCATE SIDE OF SILL PLATE HERE
(THIS SIDE UP FOR LEFT HAND)
(THIS SIDE UP FOR RIGHT HAND)
INSTALL TEMPLATE - FRONT EDGE
(THIS SIDE UP FOR LEFT HAND)
INSTALL TEMPLATE - REAR EDGE
(THIS SIDE UP FOR RIGHT HAND)
REAR OF VEHICLE
REAR OF VEHICLE
FRONT OF VEHICLE
FRONT OF VEHICLE
ALIGN TO VEHICLE EDGE
ALIGN TO VEHICLE EDGE
ALIGN TO VEHICLE EDGE
ALIGN TO VEHICLE EDGE
ALIGN TO SEAM IN INTERIOR TRIM
ALIGN TO SEAM IN INTERIOR TRIM
FRONT DOOR SILL
FRONT DOOR SILL
CHECK SCALE PRIOR
TO INSTALLATION
100mm
00
SUBARU OF AMERICA
PAGE
10 de 10
DATE
10-02-2017
NUMÉRO DESCRIPTION
Enjoliveur de seuil de porte latérale
