Subaru E101SFL100 - Page 9

SUBARU CROSSTREK SEDAN
SPN0002704 REAR ALIGNMENT TEMPLATES
REAR SIDE PLATE INSTALL TEMPLATES
2.4" (60.1mm)
5.04" (128.1 mm)
6.8" (173 mm)
LOCATE SIDE OF SILL PLATE HERE
LOCATE SIDE OF SILL PLATE HERE
(THIS SIDE UP FOR LEFT HAND)
INSTALL TEMPLATE - REAR EDGE
(THIS SIDE UP FOR RIGHT HAND)
REAR OF VEHICLE
REAR OF VEHICLE
(THIS SIDE UP FOR LEFT HAND)
(THIS SIDE UP FOR RIGHT HAND)
FRONT OF VEHICLE
FRONT OF VEHICLE
ALIGN TO VEHICLE EDGE
ALIGN TO VEHICLE EDGE
ALIGN TO VEHICLE EDGE
ALIGN TO VEHICLE EDGE
INSTALL TEMPLATE - FRONT EDGE
LOCATE SIDE OF SILL PLATE HERE
LOCATE SIDE OF SILL PLATE HERE
ALIGN TO SEAM IN INTERIOR TRIM
ALIGN TO SEAM IN INTERIOR TRIM
1.9" (50.1 mm)
REAR DOOR SILL
REAR DOOR SILL
CHECK SCALE PRIOR
TO INSTALLATION
100mm
00
SUBARU OF AMERICA
PAGE
9 de 10
DATE
10-02-2017
NUMÉRO DESCRIPTION
Enjoliveur de seuil de porte latérale
