- 45 -
Dual element
STD
Type
Fig. 5-62
(29) AIR CLEANER
Mount the air cleaner element and cleaner cover.
(28) STOP SWITCH
(1) Mount the stop switch on the blower housing.
(2) Refer to the wiring diagram (See page 51 and 52) for
wiring details.
Fig. 5-61
STOP SWITCH
