58
-
PILOT OUTLET
BYPASS
PILOT AIR JET
CHOKE VALVE
AIR INTAKE PORT
MAIN AIR JET
MAIN NOZZLE
FLOAT CHAMBER
PILOT JET
FLOAT
MAIN JET
FUEL
NEEDLE
VALVE
FLOAT
Fig. 12-2
Fig. 12-1
FUEL SYSTEM OUTLINE

Other manuals for Subaru EX17

Questions and Answers:

Subaru EX17 Specifications

General IconGeneral
Displacement169 cc
Compression Ratio8.5:1
Maximum Output4.2 kW (5.7 HP) / 4000 rpm
Ignition SystemTransistorized magneto ignition
Starting SystemRecoil starter
Dry Weight15.0 kg
Oil Capacity0.6 L
Bore x Stroke67.0 x 48.0 mm
Maximum Torque2500 rpm
Fuel Tank Capacity3.6 L
Engine Type4-stroke, OHV, single cylinder, air-cooled
