15
-
Step Parts to remove Remarks and procedures Fasteners
1 Drain the engine oill (1) Remove a drain plug (M14×12mm)
located on both sides of the case.
Take care not to lose the gaskets.
(2) To discharge oil quickly, remove the oil
guage.
14 mm spanner
Fig. 5-2
OIL GAUGE
GASKET
GASKET
DRAIN PLUG
STEP 1
5-3 DISASSEMBLY PROCEDURE
To Next Page
