Subaru EX21 - Page 55

- 52 -
8-3 MODEL WITH ELECTRIC STARTER (Model EX27)
Fig. 8-3
+M
- M
ST
B
LA108
LA408
Black
Red
Charge coil
Diode rectifier
Ignition coil
Spark plug
Key switch
Battery
(12V24AH)
Electric starter
M
agneto
Key switch
066-00003-30
-M +M BS
OFF
ON
START
8-4 MODEL WITH OIL SENSOR
To LED Lamp
Yellow
Yellow / Red
Black
Oil sensor
control unit
Orange Orange
Body
earth
Black / White
LA106
Black
To stop switch
S
park
p
lug
Oil
senso
r
Fig. 8-4
※※
※※
※ Oil sensor as option
