EX13 EX17 EX21 EX27 EX30
Type Chain-Driven OHC Chain-Driven OHC Chain-Driven OHC Chain-Driven OHC Chain-Driven OHC
Bore X Stroke (mm) 58 x 48 67 x 48 67 x 60 75 x 60 75 x 65
Displacement (cc) 126 169 211 265 287
Maximum Output (HP/RPM) 4.3/4000 SAE Test Code J1349 (Net) 5.7/4000 SAE Test Code J1349 (Net) 7.0/4000 SAE Test Code J1349 (Net) 9.0/4000 SAE Test Code J1349 (Net) 9.5/4000 SAE Test Code J1349 (Net)
Lubrication Type Splash with Chain Carry Splash with Chain Carry Splash with Chain Carry Splash with Chain Carry Splash with Chain Carry
Oil Capacity (oz./cc) 20oz./600cc 20oz./600cc 20oz./600cc 34oz./1000cc 34oz./1000cc
Fuel Tank Capacity (qt./L) 2.8 qt./2.7 L 3.8 qt./3.6 L 3.8 qt./3.6 L 6.4 qt./6.1 L N/A
Dimensions (LxWxH) mm 297 x 341 x 318 304 x 354 x 335 311 x 366 x 335" 351 x 420 x 410 415x 424 x 319
Dry Weight (lbs./kg.) 31/14 33/15 35/16 46/21 40/18
Engine
Specifications
EX35 EX40 EH09 ER12 EH65V
Type Chain-Driven OHC Chain-Driven OHC Overhead Valve Belt-Driven OHC Vertical Overhead Valve
Bore X Stroke (mm) 89 x 65 89 x 65 51 x 42 60 x 43 80 x 65
Displacement (cc) 404 404 86 121 653
Maximum Output (HP/RPM) 12/3600 SAE Test Code J1940 (Gross) 14/3600 SAE Test Code J1940 (Gross) 2.8/4200 SAE Test Code J1940 (Gross) 3.5/3600 SAE Test Code J1940 (Gross) 22.0/3600 SAE Test Code J1940 (Gross)
Lubrication Type Splash with Chain Carry Splash with Chain Carry Splash Pressure System Pressure System
Oil Capacity (oz./cc) 40.5oz./1200cc 40.5oz./1200cc 10oz./300cc 12oz./350cc 68oz./2000cc
Fuel Tank Capacity (qt./L) 7.4 qt./7 L 7.4 qt./7 L N/A N/A N/A
Dimensions (LxWxH) mm 389 x 450 x 443 389 x 450 x 443 249 x 299 x 380 228 x 286 x 322 475 x 469 x 353
Dry Weight (lbs./kg.) 73/33 73/33 22/10 22/10 93/13
Specifications subject to change without notice. | Always read the owner’s manual before use.
