Subaru F541SFL000 - Installation Procedure; Preparation and Initial Steps; Deflector Assembly and Positioning; Marking and Adhesive Application

SGD32
.1
PART NUMBER ISSUE DATE PAGE
SUBARU
2/301 01/13/2020
F541SFL000
5.
Secure the clips (C) onto the Deflector (A) with the screws (B)
and washers (G) provided. Sequence is: screw (B), washer (F),
Blade(A) and clip (C).
Read all steps before commencing & check parts list carefully.
Peel backing off foam pad (G) and attach to metal clips (C).
C
G
A
3.
.2
4.
6.
7. 8.
9.
10.
Remove masking tape.
C
B
F
COMPONENT NAME
QTY
ITEM
Screws 1
1
Clips
2
2
Ta pe 2
3
Washers
M10 Spring Washer
2
4
2
5
1
2
3
..
21
Clean the roof with soap and water. Allow to dry.
Open moon roof.
A
125mm - 130mm
CENTERED EQUALLY
=
Center the Moonroof Air Deflector on the roof, and position
125mm - 130mm from the windscreen trailing edge.
Mark Deflector bracket locations using masking tape
A
A
Remove the Deflector.
2
1
E
D
then install tape (D) to clean areas.
Clean areas shown using provided wipe (E) dry with a clean cloth
D
