1-58 Seat, seatbelt and SRS airbags
Side airbag sensor (Center pillar right-
hand side)
Side airbag sensor (Center pillar left-
hand side)
Side airbag module (Driver$s side)
Side airbag module (Front passenger$s
side)
Seatbelt pretensioner (Driver$s side)
Seatbelt pretensioner (Front passen-
ger$s side)
Seatbelt buckle switch (Driver$s side)
Seatbelt buckle switch (Front passen-
ger$s side)
Driver$s seat position sensor
Front passenger$s seatbelt tension sen-
sor
Front passenger$s occupant detection
system weight sensor
Front passenger$s occupant detection
control module
Front passenger$s frontal airbag ON
and OFF indicator
All related wiring
SRS airbag system servicing
If the warning light exhibits any of
the following conditions, there may
be a malfunction in the seatbelt pre-
tensioners and/or SRS airbag sys-
tem. Immediately take your vehicle
to your nearest SUBARU dealer to
have the system checked. Unless
checked and properly repaired, the
seatbelt pretensioners and/or SRS
airbags will not operate properly in
the event of a collision, which may
increase the risk of injury.
Flashing or flickering of the warn-
ing light
No illumination of the warning
light when the ignition switch is
first turned to the "ON# position
Continuous illumination of the
warning light
Illumination of the warning light
while driving
When discarding an airbag mod-
ule or scrapping the entire vehicle
damaged by a collision, consult
your SUBARU dealer.
The SRS airbag has no user-ser-
viceable parts. Do not use electri-
cal test equipment on any circuit
related to the SRS airbag system.
For required servicing of the SRS
airbag, see your nearest SUBARU
dealer. Tampering with or discon-
necting the system!s wiring could
result in accidental inflation of the
SRS airbag or could make the sys-
tem inoperative, which may result
in serious injury. The wiring har-
nesses of the SRS airbag system
are covered with yellow insulation
and system connectors are yellow
for easy identification.
