Connector Connecting to
No. Pole Color No. Name
F1 2 Gray Hydraulic unit
F2 2 Gray Front marker light RH
F3 1 Black F4
A/C short connector
F4 1 Black F3
F5 3 Black Headlight RH
F6 2 ★ Front fun signal light RH
F7 3 Black Sub fan motor
F8 3 Black Radiator main fan motor
F9 2 ★ Front turn signal light LH
F10 2 Gray Front marker light LH
F11 3 Black Headlight LH
F12 1 x 2 ★ Horn
F14 2 ★ Side turn signal light LH
F15 3 Gray A/C compressor
F16 1 x 2 ★
Generator
F17 2 Gray
F18 4 Black SBF holder
F19 4 Black A/C fuse (Relay holder)
F20 4 Black A/C sub fan relay-2 (Relay holder)
F21 4 Black A/C main fan relay (Relay holder)
F22 4 Black A/C sub fan relay-1 (Relay holder)
F23 4 Black A/C relay (Relay holder)
F24 2 Green Front washer motor
F25 3 ★
M/B
F26 2 Black
F27 1 Brown
F28 8 ★
F29 2 Black
F30 8 ★ B49
Bulkhead wiring harness
F31 16 ★ B50
F32 3 Orange A/C diode
F33 6 Black i6 Instrument panel wiring harness
F34 10 Gray
F/BF35 3 Gray
F36 5 Gray
F38 2 Black Horn condenser
F39 2 Black Front fog light RH
F40 2 Blue B83 Bulkhead wiring harness
F41 13 ★ P1 Power window main harness
F42 2 ★ Side turn signal light RH
F43 12 Black Hydraulic unit
F44 2 Black Front fog light LH
★: Non-colored
