25
– CONTINUED –
5-door models
1) For left seat
2) For center seat
3) For right seat
There are three anchorages on the rear
shelf behind the rear seat.
T To hook the upper anchorage strap
The upper anchorage strap is available in
the following seating positions.
V For 4-door model rear seating
positions and 5-door model rear
window-side seating positions
1. Remove the head restraint at the seat-
ing position where the child restraint sys-
tem has been installed with the anchor
bars or seatbelt; lift up the head restraint
while pressing the release button. Store
the head restraint in the cargo area. Avoid
placing the head restraint in the passen-
ger compartment to prevent it from being
thrown around in the passenger compart-
ment in a sudden stop or a sharp turn.
102095
1
2
3
y Always remove the head restraint
when mounting a child restraint
system with an upper anchorage
strap. Failure to do so may pre-
vent the upper anchorage strap
from being fastened tightly.
y Avoid placing the head restraint
that has been removed in the pas-
senger compartment to prevent it
from being thrown around in the
passenger compartment in a sud-
den stop or a sharp turn.
101743
