Suburban SFV-30 Service Training Manual

17
Figure 16
NT40
3 1/2
*
*
*
7 1/2
2 3/4
13
6 7/32
12 7/16
1/8
SUBURBAN
* 3.50" FROM CENTER LINE OF INTAKE TO
CENTER LINE OF EXHAUST
** 7.50" FROM CENTER LINE OF INTAKE TO FLOOR
HEAT SHIELD COLLAR
EXHAUST
AIR INTAKE
(2) 3.00" DIA. HOLES
INSIDE WALL
OUTSIDE SKIN
FLOOR
FURNACE
POWER SUPPLY
WIRES
THERMOSTAT WIRES
GAS LINE
SHUT-OFF VALVE
GAS LINE
ELBOW
ANCHOR TO FLOOR
MAXIMUM WALL THICKNESS 2.25"
NOTE: 0" CLEARANCE PERMISSIBLE
AT REAR OF FURNACE FOR
A WIDTH OF 2.25" MAXIMUM.
VENT CAP
Figure 17
P40
VENT ASSEMBLY INSTALLATION (NT40 & P40)
3 1/2
*
*
*
7 1/2
2 3/4
13
6 7/32
12 7/16
FLOOR
1/8
SUBURBAN
(2) 3.00" DIA. HOLES
INSIDE WALL
OUTSIDE SKIN
** 7.50" FROM CENTER LINE OF INTAKE TO FLOOR
* 3.50" FROM CENTER LINE OF INTAKE TO
CENTER LINE OF EXHAUST
HEAT SHIELD COLLAR
EXHAUST
VENT CAP
AIR INTAKE
A WIDTH OF 2.25" MAXIMUM.
AT REAR OF FURNACE FOR
NOTE: 0" CLEARANCE PERMISSIBLE
MAXIMUM WALL THICKNESS 2.25"
POWER SUPPLY
WIRES
GAS FITTING
FURNACE
ANCHOR TO FLOOR
