9
VENT ASSEMBLY INSTALLATION
VENTING
a minimum
of 1/2” on intake, and 1 1/4” on exhaust.
CAULK BEHIND VENT CAP AS SHOWN TO SEAL
BETWEEN EXHAUST AND INTAKE AND TO
PREVENT MOISTURE INSIDE FURNACE
COMPARTMENT. APPLY CAULKING GENEROUSLY
AROUND PERIMETER OF VENT CAP AND ACROSS
CENTER AS SHOWN. CENTER PUTTY STRIP IS
ESSENTIAL.
OUTSIDE SKIN (PANEL)
TUBE, INTAKE AIR
WITH GASKET
VENT CAP AND
EXHAUST
DETAIL "A"
2" MAXIMUM WALL THICKNESS
TUBE, AIR INTAKE
WITH GASKET
VENT CAP AND
EXHAUST TUBE
SEE DETAIL "A"
OUTSIDE SKIN (PAN
EL)
REMOVABLE PANEL OF
COACH WALL MUST
SEAL WATER TIGHT
FURNACE CABINET
FRONT
ELECTRICAL
CONNECTION
GAS CONNECTION
INSIDE WALL
(2) 2 1/4"
DIA. HOLES
Figure 2 • SF & SFQ MODELS
17
3"
4
8
7"
8
6
13"
16
3
13"
16
3
3"
8
2" MAXIMUM WALL THICKNESS
TUBE, AIR INTAKE
WITH GASKET
VENT CAP AND
EXHAUST TUBE
SEE DETAIL "A"
OUTSIDE SKIN (PANEL)
REMOVABLE PANEL OF
COACH WALL MUST
SEAL WATER TIGHT
FURNACE CABINET
FRONT
ELECTRICAL
CONNECTION
GAS CONNECTION
INSIDE WALL
(2) 2 1/4"
DIA. HOLES
C
L
9
4
3"
CAULK BEHIND VENT CAP AS SHOWN TO SEAL
BETWEEN EXHAUST AND INTAKE AND TO
PREVENT MOISTURE INSIDE FURNACE
COMPARTMENT. APPLY CAULKING GENEROUSLY
AROUND PERIMETER OF VENT CAP AND ACROSS
CENTER AS SHOWN. CENTER PUTTY STRIP IS
ESSENTIAL.
DETAIL "A"
VENT CAP AND
EXHAUST
TUBE, INTAKE AIR
WITH GASKET
OUTSIDE SKIN (PANEL)
Figure 2A • SH MODELS
