PARTS ILLUSTRATION AND REPLACEMENT PARTS LIST
PARTS LIST FOR MODELS: SW4DRA • SW4DFA • SW4DERA • SW4DEFA
SW6DRA •SW6DFA •SW6DERA •SW6DEFA
Only factory authorized parts are to be used.
Do not attempt to repair defective parts.
When ordering repair parts from your dealer or a distributor, always give the following information:
1. Part Number (Not Item No.)
2. Part Description
3. Model No. and Serial No. of your Heater
ITEM
NO.
DESCRIPTION
PART
NUMBER
1 Module Board 521114
3 Cover, Module Board 090613
6 Bushing, Snap 1/2" 070270
7 Bushing, Strain Relief 5/8" 230216
8 D.C. Junction Box Assembly 090517
10 Flue Collector Assembly Complete 102936
12 Valve Pressure Relief 161339
13 Screw, #8 x .375 w/ seal 122289
15 Cover, Thermostat/Hi-Limit 090562
18 Grommet 070874
20 Bracket, Electrode Mounting 063187
21 Electrode 232258
26 Burner Assembly with orice 011138
27 Air Shutter Asembly (Main Burner) 010857
28 Electric Element with Gasket 520831
29 Anode 233514
31
Connector, Electric (Gas valve
wire)
521264
34 Gas Fitting 170374
35 Bracket,Valve Mounting 063243
36 Valve, Gas (LP) 161164
37 Manifold, Outlet 171420
38 Screw #8 x .250 w/ seal 122288
39 Screw #8-32 x 3/8 121934
41
Switch Assembly, 12 V.D.C.
T-Stat/Hi-Limit
232319
ITEM
NO.
DESCRIPTION
PART
NUMBER
42
Switch Assembly, 220 V.A.C.
T-Stat/Hi-Limit
232317
45 Grommet, Gas Inlet 070989
47 AC Power Cord Assembly 090703
48 Nut, 10-24 Keps (Green) 121576
50 Foam Jacket (6 Gallon) 521267
Foam Jacket (4 Gallon) 521266
51 Switch, Lamp and Plate Assembly 232589
52
Screw, 8mm - 4.0 x 1/2 Hex
Washer Head (2 Required)
121943
53 Burner Bracket 063444
55 1/4 Loxit Nut (Manifold to Burner) 171463
56 1/4 Loxit Nut (Manifold to Valve) 171463
57 Electrode Wire (Not Shown) 232456
59 Cover, Element 090681
61
Door, Radius Corner (not shown)
(Only Radius Corner Intermediate
Frame)
6282AAW
6282APW
6282AEB
62
Door, Flush Mount (not shown)
(Only Flush Mount Intermediate
Frame)
6281APW
6281AEB
6281AAW
63 Plug Break Through 233309
65 Connector, Electric (electrode wire) 521265
66 Gasket, Screw Thread 072119
11
