5
◆
For electric screwdriver only.
Connect delivery hose Connect wire of elec. screwdriver
1. Connect feeder unit to compressed air source (air pressure 4-5 kg/cm
2
.)
2. Adjust air pressure
Connect air source Adjust air pressure
4. Check screw delivery timer setting on the front of the feeder unit. Standard operation
setting is approximate 0.5
5. Connect power cord to a single-phase AC-220 wall outlet.
Check delivery timer Connect power cord
