Owner’s Manual
®
20
Regularly clean your wheelchair using warm water and
soap solution, or a commercially available cleaner.
Clean the plastic parts with commercially available
cleaners. The seat and back rest cover should be
cleaned using warm water and soap solution,
or commercially available cleaning agents.
To remove stubborn stains use a commercially available
stain treatment. Check suitability of cleaning agent prior
to full cleaning by testing a small area of fabric for colour
fastness.
The wheelchair can be disinfected with household
disinfection agents.
5.4 Technical data
Maintenance, adjustment and repairs
may only be performed by authorised
professionals
Seat width: Adjustable (New seat canvas may be required) 50 - 53 - 56 - 59 - 62 - 65cm
Seat height: Adjustable 52.5 - 50 - 47.5 - 45 - 42.5cm
Seat depth: Adjustable 42 - 44 - 46 - 48 - 50cm
Back rest height: Adjustable 36 - 38 - 40 - 42 - 44 - 46cm
Overall width: Adjustable Seat width + 20 (+ 22 for DB) cm
Overall height: (= Seat height + back height + 2cm) From 80.5cm to 100.5cm
Total length with foot rests: 108cm
Total length without foot rests: 86cm
Weight with AR, FR, PU-wheels: 20kg
Weight with AR, FR, DB, PU-wheels: 21kg
Shipping weight without AR, FR, rear wheels. 14kg
Transit chair complete weight 22kg
Transit chair without AR and FR 17kg
Load capacity Max.: 185kg
Material: Frame and cross strut made from high-
strength aluminum alloy, powder coated
Back angle: 10.6 °
Seat angle: 2.9 °
AR = Arm rests • FR = foot rests • DB = drum brake
