F Series Manual
13
1.3.4 Rotary Module
The Rotary Module has a decagonal tangentially controlled
knife, which is driven by an electronic motor.
Depending on the used speed and knife diameter, all kinds
of materials up to 5 mm thickness can be cut with the
rotary knife.
However, the main focus is on single-layered textiles
because certain types of fibre are hard to cut with other
knife types. Ideal materials to cut with the rotary knife are:
flag & banner material, felt, technical textiles, fabric,
foams,...
The module allocates slot 2&3 of the head. It also requires
compressed air (standard on large tables).
Knives have to be mounted directly in the module; there are
no tools available for this module.
1.3.5 Router module
The router module has a motor capable of
handling most used solid boards in the graphic
and sign industry.
The router system comes with a vacuum
cleaning kit to take away the chips and dust.
The kit includes a brush assembly, a hose and a
mounting pole. The vacuum cleaner is optional.
The module allocates slot 2&3 of the head. Of
course, the module can be easily dismounted
and parked on the pole of the gantry, making
the two slots available again.
Use of a routing mat is
NOTE: The actual router module may differ from picture. Different type of the
router modules are available.
