Summerset SIZZLER - Page 22

LID HANDLE
LID
GRATE
BODY
IR BURNER
ORIFICE
RIGHT
ANGLE
ORIFICE
MOUNTING
PLATE
BRASS NUT
IGNITER PIN
KNOB KNOB BEZEL VALVE
DRIP TRAY
FLEX TUBE SHORT
FLEX TUBE LONG
BRASS INLET
FITTING
ORIFICE
FRONT PANEL
IGNITER BUTTON
IGNITER WIRE
TRL SEAR SIDE BURNER
PARTS LIST & LINE DRAWING
23 1/4"
13 3/4"
10
"
11 1/2"
18 5/8"
8 3/4"
19
