Drawer Divider Installation (for ADRD24)
In order to make better use of the drawer to store different drinks or fruits, the ADRD24 model is
equipped with two sets of drawer dividers.
1. Please find the divider accessories in the accessory plastic bag, the details of the
accessories are as follows:
Divider permanent seat (Left) 2pcs
Divider permanent seat (Right)
Movable divider
(2 rotators, 2 U-shaped tubes)
2sets
Upper drawer S.S. pipe 2pcs
2. Please follow the steps in the figure to install.
Step 1: To install 1pce right and 1pce left divider permanent seat on the two side on upper
drawer (figure 1) and lower drawer (figure 2)
Step 2: To assemble the movable divider, the parts that need to be prepared are 2pcs upper
drawer pipe, 2 U-shaped tubes and 2 rotators, please following below figure 3.
Figure 3
To Next Page
