25
Check local codes
before making
connections.
30
3
2
2
14
8
8
8
12
C
D
1/4
A
30
Min.
B
Minimum
distance to
walls above the
cooktop on
each side
18 Min.
13
Max.
5
36
8
Gas
Hookup
Area
Electrical
Connection
Area
A
A
20 3/8
24 3/8
B
2
2
C
2
3
D
2 1/2
5 1/2
Models
20 Wide
24 Wide
Installation Instructions
Pressure
regulator
Adapter
Gas Flow into Range
1/2 or 3/4 Gas Pipe
Flex connector
(4 1/2 ft. max.)
Adapter
Gas shut-off
valve
Installer: Inform the
consumer of the location of
the gas shut-off valve.
FLEXIBLE CONNECTOR
HOOKUP (Example)
RIGID PIPE HOOKUP (Example)
Installer: Inform the consumer of the
location of the gas shut-off valve.
Pressure
regulator
Black iron
pipe 4 1/2
90° Elbow
Nipple
(may not
be needed)
Gas Flow into Range
1/2 or 3/4 Gas Pipe
Gas shut-off
valve
Nipple
Union
Black iron
pipe
90° Elbow
RECOMMENDED GAS AND ELECTRIC SUPPLY LOCATION
NOTE: Recommended gas hookup
locations behind range. Gas fittings
and shut-off valve should NOT
protrude more than 2" from the wall
to allow the range to fit against the
wall.
