LOCATION OF PARTS
CH-SERIES WINE CELLARS
Models shown: SCR1401CH (left), SCR611GLOSCH (right)
1. Digital control panel* (located in front kickplate on SCR610/11)
2. Power button
3. Light switch (upper panel & front grille on SCR1401; front grille on all others)
4. Digital display and controls
5. Adjustable bottle shelf
6. Shelf clips (pre-installed for angled display but can be adjusted by user)
7. Door handle
8. Ventilation grille
9. Security lock
10. Adjustable leveling legs
