LOCATION OF PARTS
X-SERIES WINE CELLARS
Model shown: SCR1401X
Type equation here.
1. Digital control panel* (located in front
kickplate on SCR610/11)
2. Power button
3. Light switch (upper panel & front grille
on SCR1401; front grille on all others)
4. Digital display and controls
5. Door handle
6. Ventilation grille
7. Security lock
8. Adjustable leveling legs
1
X-series cellars feature fixed
diamond shelving racks designed to
store bottles horizontally as shown
on the right
