It has
been mentioned
that the
djesel
engine
sensitively
responds
to
changes
of the
start
of
injection.
The
beg'inning
of
del'ivery
strongly
influences the
efficiency
of the
diesel
engine. For example,
if
you
have
a
passenger-vehicle
diesel-engine
of
60
kW
and the
beginning
of
delivery
is
changed
by
only 3 degrees
crank
angle, the
power
drops 6 kW,
the torque
9
Nm
and
the
smoke
blackening
rises
TESTER HOOK-UP
Refer
to
page
49
to
set-up the
tester.
WARNING
A. Do not make
connections to
a
vehicle
before the main lead
of
the
tester is
connected
to
the
proper
socket outlet.
B.
Do not
disconnect the
mains lead
before
you
disconnect the
connections to the vehicle.
If the
testelis
not
connected
to
earth, dangerous voltages
can be
present
on
the casing
of
the
tester.
CAUTION
Keep the test
leads
away from moving
or
hot
engine
parts.
The test leads
can
not
withstand
high
temperatures
or severe mechanical
stress.
Select
a straight
part
of
the injection
line'of
cylinder number 1,
as
close as
possible
to the injection
pumpr
or
a'location
specified by the
vehicle
manufacturer.
Clean the
clamping
spot with
emery
cloth,
remove
any
paint
or oil
The
clamp'ing
spot must
be undamaged
and
perfectly
clean.
Note:
The
clamp-on
transducer,
type
KG
6, supplied
as a standard with
the
diesel
kit
option is
suitable for the
6 mm lines.
C'lamp-on
transducers
with
other sizes ranging from
4.5
mm to 12.7 mm
are
available
through
your
1ocal
Sun
representat'ive.
carefully fit the
clamp-on transducer
to the
straight
and cleaned
portion
of the line,
without
turning
or sliding the
transducer, as the
measuring
areas
of the transducer
can be
easily
damaged.
clamp the
ground
cl'ip firmly
onto
a
paint-free
part
of
the injection
pump
Attach
the
push-on
terminal
of the transducer
lead
to the
clamp-on
transducer.
(see
figure
38).
oPTIoN Install
the
mag
probe
in
the receptacle,
if required
use the
adapter.
Connect the
mag
probe
to the
universal harness.
2
3
4
5
6
Page
68
