4. If you have a Pair of Gates then……….
Connect the Slave to the Master Unit with 2 Core Flex-Cable [Max load draw 8 Amp at 12
Volts]
[Fig.8 cable - .75mm sq – 24/.020 minimum] Refer Fig. 3
All cabling must not be run in conjunction with any high voltage cables or electric fencing – if in doubt,
seek advice from a qualified Electrician in Your State or Territory.
