Preparation: Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents above. If any part is missing or damaged, do not attempt to assemble the product.
Contact customer service for replacement parts.
Tools Required for Assembly (not included):
Phillips screwdriver with medium blade
Assembly
1-877-387-3639 | Page 7
1
3
2
4
1. Attach Door Knob (H) to Door Panel (I).
3. Attach Right Side Panel (J) and Left Side Panel (C) to the Back Panel (B)
and to the Door Panel (I).
DO NOT OVERTIGHTEN as you will need to adjust the holes to ensure proper
alignment.
AA M6x10 Bolt x8 CC M6 Washer x8
4. Open the door, attach control box to Left Side Panel (C).
AA M6x10 Bolt x1 CC M6 Washer x1
2. Place Table Top with Burner (A) upside down on a flat, protected surface.
Attach the Back Panel (B) and Door Panel (I) to the Table Top with Burner (A).
DO NOT OVERTIGHTEN as you will need to adjust to ensure proper alignment.
AA M6x10 Bolt x8 CC M6 Washer x8
BB M6x25 Bolt x1 CC M6 Washer x1
AA
I
B
CC
A
AA
CC
C
AA
C
J
I
B
CC
BB
H
CC
