Sunbeam BC1712G - Assembly Instructions Part 3; Step 7: Attach Lid to Grill Bottom; Step 8: Attach Warming Rack; Step 9: Insert Heating Plate and Cooking Grid

Owner’s Manual,
Model BC1712G Portable Gas Grill
BC1712G owner’s manual
7
M
L
5
8
Step 7
Attach lid (1) to grill bottom
(2) at hinges (10, 11), using
pins (L), and cotter pins (M)
as shown.
Step 8
Attach warming rack (12) to grill
by inserting into holes, as
shown.
Step 9
Insert heating plate (8) and cooking
grid (5) into assembled grill, as
shown.
Note: When assembling the cooking
grid (5), assure that the curved side
faces the front of the grill.
12
