EM9300 Café Bellissimo Issue: A Page 2 of 21
SPARE PARTS LIST
Note: Not all parts are available as spare parts. Please check price list.
Item
Description
Material Specification
No. of Parts
Supplier’s Cod
e
Sunbeam Part No.
1 Housing Cover Left 1
9310231600
2 Housing Top Cover 2 9310197700
3 Housing Cover Right 3 9310197800
4 HSG Lower Part Ass'y 4 9310197000
5 Assembly Milk Box 5 9310231200 EM9300MB
6 Freezer Ass’y 6 9310232200
7 Drip Tray Assembly 7 9310197900 EM930010
8 Brew Unit Assembly 8 9310166500 EM930011
9 Middle Plate 9 9310176200
10 Plug For Communication
Connector
10 9310176400
11 Inner Housing Lower Part 11 9310176300
12 Leg Spring Support Ass'y 12 9310176500
13 Top For Middle Plate 13 9310176600
14 Air Duct Housing Ass'y 14 9310176700 EM93002
15 Bean Container Ass'y 15 9310176800 EM93003
16 Waste Container Assembly 16 9310198000 EM930012
17 Assembly Pump Without Strap 17 9310188200 EM93004
18 Water Tank Assembly 18 9310231700 EM930013
19 Motor Ass'y Without PCB 19 9310188000
See item 19+78
19+78
Motor Ass'y With PCB
9310166900
EM93005
20 Flow Meter 20 1310000600 EM93006
21 Belt Pulley Z 59 21 3010542500 EM93007
