Sunbeam Juice Stream JE5200 User Manual

Disassembling your juicer
1. Turn the power ‘Off’ at the power outlet
and unplug the cord.
2. Slightly tilt the pulp container and slide
away from the juicer – figure 8.
3. Place fingers under the bottom of
the twin-locking handles and lift
to release – figure 9.
4. Lift the juicer cover from the juice
collector/bowl – figure 10.
5. Place fingers under the rim of the
stainless steel blade and filtering
basket and lift out – figure 11.
Important: Juicing blades are very sharp,
handle juicing filter basket with care
when removing, replacing and cleaning.
6. Lift the juice collector/bowl from the motor
base – figure 12.
Figure 9
Figure 10
Figure 11
Figure 12
Figure 8
11
