Sewing Machine InstructionsPage 4
Preparations for Use
Plug one end of the adapter into the DC socket on the sewing •
machine, and the other end into an outlet.
Plug the foot control into its socket. •
Turn the power switch on.•
Caution: Always turn the switch on off before un-plugging the
machine.
Operating Instructions
Winding the bobbin
Place a spool of thread on the Spool Pin. 1.
(Figure 1) (Make sure that the machine’s
needle is not threaded at this time.)
Place the metal bobbin on the bobbin winder, 2.
making sure to insert it in the groove. (Figure
2) (Note: It is important to use metal bobbins
only. The Bobbin Case is magnetized and is
activated with metal.)
Guide the thread from the Spool Pin through 3.
the thread clamp (Figure 3) and to the bobbin.
Wind a small piece of thread around the
bobbin
clockwise.
(Figure 4)
Move the 4.
bobbin
Figure 5
Figure 2
Figure 1
Figure 4Figure 3
