SUNBEAMsystem MOONRAY 320 - Page 54

52 WWW.SUNBEAMSYSTEM.COM
“User settings” congurable parameters - suggestions ( 2 x for 24V system)
Lithium batteries requires:
Over Voltage Reconnect=Charging Limit, Equalize Charging=Boost Charging
Over Voltage Disconnect should be set slightly higher than the BMS auto shutdown voltage.
12.6V
11.7V
12.6V
11.7V
12.8V
12.6V
12.8V
12.6V
12.8V
12.6V
Low Voltage Reconnect (Load port on)
Low Voltage Disconnect (Load port off)
LOAD/TIMER PORT LOW VOLTAGE SENSOR
14.2V
14.2V
13.5V
13.2V
0 min
120 min
14.4V
14.4V
13.5V
13.2V
0 min
120 min
14.4V
14.4V
13.5V
13.1V
0 min
120 min
14.5V
14.5V
13.5V
13.2V
0 min
120 min
14.5V
14.5V
13.4V
13.0V
0 min
60 min
Equalize Charging
Boost Charging
Float Charging
Boost Reconnect
Charging
Equalize Duration
Boost Duration
FOUR STAGE CHARGE PROGRAM PARAMETERS
GEL
(CONS.)
AGM
(TYPICAL)
SMART
LITHIUM
(CONSERV.)
SMART
LITHIUM
(MAX)
LiFePO4
(COMMON)
-3mV/C/2V
15.0V
10.6V
-
-4mV/C/2V
15.0V
10.6V
-
0
14.6V
12.5V
-10
0
14.6V
12.5V
-35
0
14.6V
12.5V
-0
Charge compensation
Charging Limit
(max temp comp.)
Discharging Limit (min temp comp)
Lithium min temp limit
SETTINGS BATTERY TYPE
TEMPERATURE CHARGE
COMPENSATION
15.2V
14.4V
12.2V
12.0V
15.4V
14.4V
12.2V
12.0V
15.1V
14.6V
12.8V
12.7V
15.1V
14.6V
12.8V
12.7V
15.1V
14.6V
12.8V
12.7V
Over Voltage Disconnect
Over Voltage Reconnect
Under Voltage Warning
Reconnect
(LCD icon)
Under Voltage Warning (LCD icon)
BATTERY FAILURE PROTEC. & DISCHARGE WARNING
