APPENDIX
Battery Voltage Control Parameters
Onboard available preset charge proles (Values 2 x for 24V battery system)
Setting parameter limitations
Over Voltage Disconnect = Charging Limit, Equalize Charging Voltage = Boost Charging Voltage, Float
Charging Voltage = Boost Reconnect Charging.
For a stable setup Float Charging should be 0.4V higher than Boost reconnect charge
- Over Voltage Disconnect > Over Voltage Reconnect
- Low Voltage Reconnect > Low Voltage Disconnect ≥ Discharging Limit.
- Under Voltage Warning Reconnect > Under Voltage Warning ≥ Discharging Limit.
- Boost Reconnect Charging >Low Voltage Reconnect.
SETTINGS BATTERY TYPE
FLOODEDGELSEALEDTEMPERATURE CHARGE COMPENSATION
-3mV/C/2V
15.0V
10.6V
-3mV/C/2V
15.0V
10.6V
-3mV/C/2V
15.0V
10.6V
Temp. Compensation Coefficient
Charging Limit (low temp. - max Volt)
Discharging Limit (high temp – min Volt)
BATTERY FAILURE PROTEC. & DISCHARGE WARNING
16.0V
15.0V
12.2V
12.0V
16.0V
15.0V
12.2V
12.0V
16.0V
15.0V
12.2V
12.0V
Over Voltage Disconnect
Over Voltage Reconnect
Under Voltage Warning Reconnect (LCD icon)
Under Voltage Warning (LCD icon)
FOUR STAGE CHARGE PROGRAM PARAMETERS
14.6V
14.4V
13.8V
13.2V
120 min
120 min
——
14.2V
13.8V
13.2V
——
120 min
14.8V
14.6V
13.8V
13.2V
120 min
120 min
Equalize Charging
Boost Charging
Float Charging
Boost Reconnect Charging
Equalize Duration
Boost Duration
LOAD/TIMER PORT - LOW VOLTAGE SENSOR
12.6V
11.1V
12.6V
11.1V
12.6V
11.1V
Low Voltage Reconnect (Load port ON)
Low Voltage Disconnect (Load port OFF)
