Sunbuck AS60BU - Product Layout and Controls; Front Panel Overview; Rear Panel Connections

Product layout:
MODE
ON
OFF
1 2 3 4 5 6
7
8
9 10
11 12
13 14
AS-60BU
1. Power switch
2. USB Plug
3. Micro SD Plug
4. Display Screen
5. MP3 Button
6. Master Volume
7. Aux input,
19. Right Speaker Output
20. LEFT Speaker Output
21.AC Power Fuse(3A or T3.15A)
22.AC100-240V Power Input
8. Signal Exchange Knob
9. Bass
10. Treble
11. MIC Echo
12. MIC Tone
13. MIC Volume
14. MIC1/MIC2 Input
15. CD Input
16. LINE Input
17. FM Antenna Input
18. 12DC Power Input
100-240Vac,50/60Hz
FUSE:T3.15A 250V
-
+
DC 12V
15
16 17 18 19
4- 8Ω
20 21 22
/C H-
/C H+/S CAN
