Suncast BMDB134004 - Assembly Steps 16-19 (Parts Box B); Completing Box B Assembly and Locking

13
Align lid ( E) to Back panel ( C).
NOTE: Two person assembly required for steps 11 - 12.
hmi
14
Lower the lid onto base, inserting bolt ( EE) into side. Use nut ( GG) to secure the
bolt ( HH) through the lower hinge and the side panel. Use nut ( FF) to secure bolt
(EE). Tighten with wrench.
Repeat for the other side.
15
To properly lock the unit, a 5/16" padlock is recommended.
NOTE: Lock not included.
9
