Suncast BMDB134004 - Assembly Steps 1-4; Connecting Base and Side Panels

55
At an angle, insert the three hooks on (C) into either long side of bottom (A).
Rotate (C) upright to lock the hooks.
Insert the two tabs on (C) into (B).
2
3
4
NOTE: During assembly, position all parts with wicker side out. Insert
the two hooks on (B) into either short side of (A). Push straight down. You
may hear a “snap” when tabs are fully engaged. Use force to push down.
1
tab
Insert the two hooks on (B) into other short side of (A). Push straight
down. You may hear a “snap” when tabs are fully engaged.
Repeat step 3 to connect (B) to (C).
Smooth Side Up
Floor
B
A
2
C
A
C
B
C B
C
A
B
