Suncast BMS8125 - Ridge Beam Assembly

15
Ridge Beam Pre-Assembly
Place ridge beam joiner (DDD) into the 3' ridge beam
(EEE). Secure with hex bolt (MM) and nut (LL).
Part (EEE) orientation is critical, see picture.
Place 7' ridge beam (V) onto the ridge beam joiner
(DDD). Secure with hex bolt (MM) and nut (LL).
