Suncast Covington BMS7425 - Page 15

15
1
2
11
C
Tip left front (C) back to vertical position and align lower
tabs on right side with slots in floor.
Note: You will hear a snap when tab is fully engaged.
Shed Assembly/Walls (continued)
C
Side viewSide view
Top viewTop view
Before proceeding, make sure
corner is square (top view) where it
meets the floor and that panel is flush
(side view) with floor.
If not, repeat Steps 8–11
until square and flush.
12
Align tab on bottom left side of back corner (E) with slot
on front floor (A). Lower panel into slot and lock in place
by sliding panel toward front corner.
Note: Use a rubber mallet to “push” back corner (E)
into locked position.
1
2
13
E
A
1
22
14
E
Tip back corner (E) outward slightly and bend corner
hinge.
