Shed Assembly/Walls (continued)
Tip back corner (E) back to vertical position and align
lower tabs on left side with slots in floor.
Note: You will hear a snap when tab is fully engaged.
E
Rear viewRear view
Top view
Top view
Before proceeding, make sure
corner is square (top view) where it
meets the floor and that panel is flush
(rear view) with floor.
If not, repeat Steps 13–15
until square and flush.
16
17
GG
x4
Secure back corner with four easy bolts (GG). Work
from floor to roof. DO NOT use torque wrench. Use
easy bolt easy driver (XX) and hand tighten. Easy bolt
head will be flush when fully seated. DO NOT over
tighten easy bolts.
Note: You may hear a click when easy bolt has been
tightened completely.
