Using This Manual:
Organization
This manual is part of the final data package for the Sundyne LMC/BMC Phoenix compressor. In addition
to this manual, the final data package includes such information as the following:
Drawings, Sundyne specification sheet with test performance curves, test data, inspection data, material
certificates if required; and auxiliary equipment information. When using the specification sheet, section 1
of the final data package, and drawings, last section of final data package, in this manual compare the
release date with those in the maintained final data package to ensure that you are using the most
current information. This manual explains procedures for the Sundyne compressor, including how to:
install it, maintain it, service it, troubleshoot problems; and order parts. Whenever you talk or write to your
Sundyne representative, provide your compressor’s unique serial number.
This manual contains the following sections:
1. Installation
Describes how to install the compressor and how to store it until you install it.
2. Lubricating Oil System
Provides the following information: how to prepare the gearbox for start-up; how the lubricating oil
system works; and specifications for gearbox lubricants.
3. Start-up
Provides a procedure for starting and controlling the compressor. A critical start-up checklist is
included as Reference A.
4. Servicing
Provides procedures for servicing the compressor.
5. Maintenance of the Seals and Process End Disassembly
Provides procedures for disassembling the LMC/BMC compressor and its seal housings.
6. Gearbox Disassembly
Provides procedures for disassembling & reassembling the gearbox of the compressor.
7. Inspection of Disassembled Hardware
Provides procedure for inspecting the disassembled hardware.
8. Checking and Setting High Speed Shaft End Play
Provides procedure for checking and setting high speed shaft end play.
9. Gearbox and Process End Reassembly
Provides detailed reassembly procedure of gearbox and process end.
