10. Troubleshooting
Provides tables for the following:
a) Looking up a problem.
b) Identifying the possible cause.
c) Selecting the corrective action.
11. Operation
Provides general guidelines for controlling a compressor such as surge control, suction throttling,
discharge throttling, and speed control.
12. Spare Parts
Contact and reference information.
13. Sundyne Compressor Warranty
Provides a warranty statement for the compressor/gearbox unit.
Reference A
Critical Start-up Checklist
Reference B
Lock-out/Tag-out Guidelines
Reference C
Seal Arrangement Drawings for single, double, and tandem configuration
Reference D
Phoenix Compressor/Gearbox Drawings
1. Installation
This section provides an introduction to the compressor, procedures for inspecting and installing it, and
procedures for storing it if you are not installing it immediately. It contains a subsection on each of the
following:
Introduction:
This provides a brief description about the compressor and how it is used.
Inspection:
As soon as you receive the compressor, inspect it thoroughly.
Short-term Storage:
If the unit will be installed within 6 months follow these procedures.
Long-term Storage:
If the unit will not be installed within 6 months follow these procedures.
Suction and Discharge Piping:
Follow these procedures to set up the piping for suction and discharge.
Seal Environment Control System:
Follow these procedures to set up the seal environment controls,
even if you use the standard system supplied by the factory.
Baseplate Grouting:
Use this information for applying grouting to the baseplate.
Horizontal Unit Gearbox Support Bracket:
Follow these procedures to drill and pin the gearbox
support bracket on a horizontal unit.
Driver and Coupling:
Follow these procedures to align the driver and the compressor. Do this after
grouting, and before you connect the piping for suction and discharge.
