6614A REV. A 7 rev. 9/11/19
1 * Snap ring 1
2 * Washer 2
3 * O-ring 1
4 Piston Rod 1
5 * Piston ring 1
6 * Sealing washer 1
7 * O-ring 1
8 * O-ring Retainer 1
9 * Snap ring 1
10 Oil cylinder assembly 1
11 * Oil Filler Plug 2
12 * Steel ball 1
13 * Ball seat 1
14 * Spring 1
15 Screw 1
16 * Sealing washer 1
17 Bolt 1
18 * Steel ball 1
19 * Copper washer 1
20 Bolt 1
21 * Steel ball 1
22 * O-ring 1
23 * O-ring 1
24 RS6620D24 Release valve Rod Revision E 1
29 * O-ring 2
30 * Washer 2
31 Cylinder Pump Plunger 1
32 ** Copper washer 2
33 RS6620BH26 Oil valve assembly 1
34 ** Nylon Gasket 1
35 Pump cylinder 1
36 ** Oil seal 1
37 ** Nylon Gasket 1
38 ** Copper washer 1
39 Nut 1
40 Bolt 8
41 Front cover 1
42 ** Steel Ball (3) 4
43 Air Pump Housing 1
44 Nut 1
45 Spring 1
Index No. Part No. Description Qty. Index No. Part No. Description Qty.
PARTS LIST FOR HYDRAULIC UNIT/AIR MOTOR
46 Washer 1
47 Cylinder Pump Plunger 1
48 Piston Body "A" 1
49 ** O-ring 2
50 Air Release Rod 1
51 ** O-ring 2
52 Piston Body "B" 1
53 Bolt 3
54B Air Seal Revision D 1
55 ** O-ring 2
56 ** O-ring 1
57 Rear cover 1
58 Snap Ring 1
59 ** O-ring 2
60 screw 1
61 RS6620B61 Air valve and hose 1
62 O-ring 3
63 ** Nylon washer 2
64 Steel Ball 2
65 Process Plug 2
66 * Filter Screen 1
67 Throttle Valve 1
68 * Copper Washer 1
69 Bolt 1
70 Bolt 1
71 Washer 1
72 Nut 1
73 RS6620BAR Complete Air Motor Assembly Rev. E 1
74 RS6614A59B Complete Hydraulic Assembly 1
A Screw 1
B * Copper washer 1
C * Spring 1
D * Steel Ball (9) 1
E * Steel Ball (6) 1
F Oil box 1
G Screw 1
H * Washer 1
I * Washer 1
J Nut 2
K RS6614AK Hose (incl. J, K (2)) 1
M Spring 1
Only index numbers identified by Part Number are available separately. * Only available in hydraulic repair kit RS6620DHRK. ** Only available in air motor repair kit RS6620DARK.
1 Frame 1
2 Washer 4
3 RS660903 Front Wheel (incl. #2, 3, 3-1, 4,5) 2
3-1 RS660903A Roller Bearing Set 2
4 Snap Ring 2
5 Grease Fitting 5
6 Rod Link 2
7 Bolt 2
8 RS660908 Saddle 1
9 Lock Washer 2
10 Nut 2
11 Spring 1
12 Bolt 1
13 Bolt 2
14 Lock Washer 2
15 Shaft 1
16 Washer 2
17 Lock Washer 2
18 Nut 2
19 RS660916 Rear Wheel Assembly 2
20 RS660917 Caster Bolt Kit Assembly - incl. #20 (2), 21 (2) 2
21 Washer 4
22 Washer 4
23 Bolt 4
24 Snap Ring 2
25 Shaft 1
26 Washer 1
27 Pin 1
28A Link Assy. 1
29 RS660929 Spring 1
30 RS550510 Snap Ring -12 mm Diameter 2
31 RS550509 Pedal Pin 1
32 Pin 1
33 Pin 1
34 RS6614A59B Complete Hydraulic Power Unit 1
35 Cover Plate 1
36 RS660932 Handle Socket 1
37 RS550511 Pedal 1
38 Nut 1
39 Washer 1
40 RS550535 Bolt Kit (Incl. 38, 39, 40) 1
41 Handle 1
42 Hand Grip 2
43 RS660939 Knob (incl. 43, 44) 1
44 Pin 1
45 Control Rod 1
46 Spring 1
47 Washer 2
48 Screw 2
49 Rod Joint 1
50 Spring 1
51B RS6614A51 Release Flex Shaft 1
52 Convey Rod 1
53 Washer 1
54 Pin 2
55 Pin 1
56 Washer 1
57 Ring 2
58 Screw 1
59 Washer 1
60 Washer 1
61 Hose Retainer 1
62 RS661457 Complete Handle Assembly (incl. 41-49, 52-56) 1
RS6614ALK Product Label Kit (not shown) 1
Index No. Part No. Description Qty. Index No. Part No. Description Qty.
6614A
CAPACITY: 10 TON @ 100 PSIG
AIR/HYDRAULIC SERVICE JACK
PARTS LIST
