Sunex HD 6622 - Power Unit Assembly RS662246; Air Pump Assembly RS662270

6622
CAPACITY: 22 TON
AIR/HYDRAULIC TRUCK JACK
REF # PART# DESCRIPTION QTY
1 RS6622121 Adapter 1
2 RS6622222 Spring Holder 1
3 RS6622221 Spring 4
4 Screw Rod 1
5 Bushing 1
6 RS662220 Piston Rod 1
7 * Back-Ring 1
8 * U-Seal 1
9 Piston 1
10 Snap Ring 1
11 * Dust Seal 1
12 Tank Nut 1
13 * O-Ring 1
14 Oil Tank 1
15 RS6622227 Breathing Screw 1
16 * Packing 2
17 * O-Ring 1
18 Screw 4
19 Nut 4
20 RS662228 Cylinder 1
21 Screw 3
22 Spring Washer 3
23 * Oil Strainer 1
24 * O-Ring 3
25 * Backup Ring 1
26 Oil Box 1
27 Washer 1
28 Washer 1
29 * Safety Valve 1
30 * Spring 1
31 * Screw 1
32 Screw 1
33 * Steel Ball 1
34 * Separator 1
35 * Steel Ball 1
36 * Spring 1
37 * Copper Packing 1
38 Bolt 1
REF # PART# DESCRIPTION QTY
1 RS662281 Plunger Cover 1
2 Nut 1
3 Air Pump Body 1
4 * Ball 1
5 Spring 1
6 Nut 1
7 * O-RIng 1
8 * NL Retainer 1
9 * Packing Guide 1
10 Plunger 1
11 * O-Ring 2
12 Piston 1
13 Washer 1
14 * O-Ring 2
15 Retainer 1
16 * Packing Washer 1
17 Muffler Cover 1
18 Pipe Joint 1
19 Valve Rod 1
20 * Packing Washer 1
21 * Rubber Pad 1
22 Cover 1
23 * Filter Element 1
24 Filter Cover 1
25 Spring Washer 4
26 Hex-Socket Screw 4
POWER UNIT ASSEMBLY RS662246
AIR PUMP ASSEMBLY RS662270
1 2 3 4 5 6 7 8 9 10 11 11 12 13 14 15
16
17 18 19 14 20 21 22
23
26
24
25
1
2
3
4
5
6
8
7
9
10
11
12
13
14
15
16
17
18
19
23
20
18 19
21
22
25
24
26
27
28
32
16
31
30
29
38
37
36
35
34
33
* Available in RS6622HRK.
Only items identified by part number are available for purchase.
* Available in RS6622AMK.
Only items identified by part number are available for purchase.
