PARTS LIST AND DRAWING
PREVENTATIVE MAINTENANCE
This is the safety alert symbol used for the PREVENTATIVE MAINTENANCE section of this manual to alert you to potential personal
injury hazards. Obey all instructions to avoid possible injury or death.
1. Always store the jacks stands in a well protected area where they will not be exposed to inclement weather, corrosive vapors,
abrasive dust, or any other harmful elements. The stands must be cleaned of water, snow, sand, grit, oil, grease or other foreign
matter before using.
2. Every jack stand owner is responsible for keeping the stand labels clean and readable. Use a mild soap solution to wash external
surfaces of the stand. Contact Sunex for a replacement label if your stand's label is not readable.
3. Inspect the stands before each use. Do not use the stands if any component is cracked, broken or bent. Do not use the stand if it
has loose or missing hardware or components, or is modified in any way. Take corrective action before using the stand again.
Premature wearing or damage to components caused by loose or missing hardware is not
eligible for warranty consideration.
1
4
2
3
5 6
7
8
Note:
Only items identied by part number are available for purchase.
ITEM NO PART NO DESCRIPTION QTY
1 RS100301 Bolt M8 x 80 1
2 Base 1
3 Sleeve 1
4 RS100304 Nut M8 1
5 RS3TPRCS Lock Pin (incl. item 6,7) 1
6 Key Ring 2
7 Chain 1
8 Saddle and Post 1
Not Shown RS1003AJLK Label Kit 1
MODEL 1003AJ
CAPACITY: 3 TON
JACK STAND (PAIR)
