Sunex Tools 4910A - Parts List and Drawing

4910A 6 03/18/19
A. PUMP
B. HOSE
C. RAM
D. SPREADER
Item # Part # Description Quantity
A RS10TP Pump (Incl. Hose) 1
B RSHS Hose 1
C RS10TR Ram 1
D RSSPR Spreader 1
01 RS10T01 Case 1
RS10T01WH Wheel w/ Hardware for Case 2
02.1 RS10T02.1 4.33" (110mm) Extension 1
02.2 RS10T02.2 10.43" (265mm) Extension 1
02.3 RS10T02.3 14.37" (365mm) Extension 1
02.4 RS10T02.4 20.47" (520mm) Extension 1
Item # Part # Description Quantity
03 RS10T03 Flat Base 1
04 RS10T04A Ram Toe 1
05 RS10T05 Plunger Toe 1
06 RS10T06 Wedge Head 1
07 RS10T07 V-Base 1
08 RS10T08 Male Connector 1
09 RS10T09 Serrated Saddle 1
10 RS10T10 Rubber Head 1
11 RSPG Pressure Gauge 1
4910A
10 TON RAM KIT
PARTS LIST AND DRAWING
MODEL 4910A
CAPACITY: 10 TON
PORTABLE RAM KIT
