Sunex Tools 4910A - Pump Parts List and Drawing

4910A 7 03/18/19
A
RS10TP
10 TON PUMP
PARTS LIST AND DRAWING
Items identified by an asterisk are available in pump seal kit, RSPSKA.
Item # Part # Description Quantity
PO1 Valve Block 1
PO2 Oil Filter 1
PO3 * O-Ring 2
PO4 Reservoir 1
PO5 Tie Rod 1
PO6 Nylon Ring 1
PO7 Oil Filler Screw 1
PO8 Sealing 1
P09 RSP09A Breather Valve (Incl. #6-9) 1
P10 Screw 1
P11 * O-Ring 2
P12 RSP12 Pump Foot 1
P13 * Ball 2
P14 * O-Ring 1
P15 RSP15 Release Valve 1
P16 RSHS Hydraulic Hose 1
P17 RSP17 Coupler 1
P18 RSP18 Hose Dust Cover 1
P19 * Ball 1
P20 Ball Cap 1
P21 * Spring 1
P22 Screw 1
P23 * O-Ring 1
P24 Screw 1
P25 Screw Protector 1
P26 * Nylon Ring 1
P27 * Valve Base 1
P28 Valve Cover 1
Item # Part # Description Quantity
P29 * Washer 1
P30 * Seal 1
P31 * O-Ring 1
P32 * Washer 1
P33 Screw 1
P34 * O-Ring 1
P35 * Washer 1
P36 Piston 1
P37 Pin 1
P38 Retaining Ring 2
P39 Pin 1
P40 Handle Socket 1
P41 RS10TP41 Handle (Incl. #42) 1
P42 Handle Sleeve 1
P43 Screw 1
P44 * Spring 1
P45 * Steel Ball 1
P46A RSPGAA Gauge Adapter Assembly 1
P49 RSPG Pressure Gauge 1
P52 * Nylon Ring 1
*
NOTE: Items which are not identified by a part number or with an asterisk are not available separately.
MODEL 4910A
CAPACITY: 10 TON
PORTABLE RAM KIT
