4910A 8 03/18/19
RSSPR
SPREADER PARTS BREAKDOWN
Items identified by an asterisk are available in Spreader Seal Kit, RSSPRSK.
Items identified by an asterisk are available in Ram Seal Kit, RS10TRSKA.
*
*
NOTE: Items which are not identified by a part number or with an asterisk are not available separately.
NOTE: Items which are not identified by a part number or with an asterisk are not available separately.
Item # Part # Description Quantity
S1 Pin 1
S2 Circlip 2
S3 Movable Jaw 1
S4 Spring 1
S5 Fixed Jaw 1
S6 Piston 1
S7 * Cup Seal 1
S8 * O-Ring 1
S9 End Cap 1
RSCPRA Coupler 1
RS10TR
RAM PARTS BREAKDOWN
Item # Part # Description Quantity
R01 RS10TR01 Cover 1
R02 Circlip 1
R03 Piston Rod 1
R04 * Circlip 1
R05 * Bushing 1
R06 * Nylon Ring 1
R07 * Sealing Ring 1
R08 * Circlip 1
R09 Nut 1
R10 Spring 1
R11 Screw 1
R12 RS10TR12 Protection Cap 1
R13 Ring for Ram 1
R14 Cylinder 1
R15 Screw 1
RSCPRA Coupler 1
(Includes: S10, S11, P11, S12, S13)
(Includes: S10, S11, P11, S12, S13)
MODEL 4910A
CAPACITY: 10 TON
PORTABLE RAM KIT
